Dust Collector with Fan
Basic Introduction
A stand-alone dust collector is a dust collector that can operate when connected to an air duct and power supply. This type of dust collector has a small volume and requires no manual operation. The air volume is 1000-6000m3/h, and the filtering wind speed is 1.2-1.8m/min if using 740 filter cloth, and 2.0-2.8m/min if using polyester filter material.
structure performance
Single machine dust collector unit, dust collector is an air purification equipment with small volume and high dust removal efficiency. Suitable for various independent dust generating points, flexible and convenient, on-site dust collection and treatment can effectively ensure the cleanliness of the air. The basic structure is composed of a dust collector box, a centrifugal fan, a filter bag (cartridge), a dust collector, and a microcomputer controller. The dust is sucked into the interior of the dust collector box by the negative pressure of the fan through the dust suction pipe, using gravity and upward airflow. First, the coarse dust is initially filtered by the filter and directly drops to the dust collector. The particulate dust is collected on the outer surface by the filter, and the clean gas flows into the clean room after being filtered, decomposed, and purified by the filter element, So as to be discharged from the air outlet by the fan. The entire dust removal and filtration process is the result of a comprehensive effect of gravity, inertial force, collision, electrostatic adsorption, and filtration.
Scope of use
Single unit dust collectors can be widely used in the pharmaceutical industry and other industries such as biology, chemical industry, food, electronics, mechanical hardware, casting, ceramics, loading and unloading, mining, metallurgy, etc. for on-site dust removal. For general small specific gravity, fine metal chips, foundry sand dust, cement, gypsum powder, carbon powder, bakelite powder, plastic powder, etc., all have good dust removal effects within a certain range, with a dust removal efficiency greater than 99.5%.
